Small and Utility Clamps with Full-Functions.

SK-7660／7661AC/DC
DIGITAL CLAMP METER

  • SK-7660 Photo
    • TRUE RMS
    • 27mm
    • CE

  • Measurement Items

      • AC/DC A
      • AC/DC Current (400A)
      • AC/DC V
      • AC/DC Voltage
      • Ω
      • Resistance
      • Frequency
      • Frequency
      • Continuity Test
      • Continuity Test
      • Diode Test
      • Diode Test
      • Duty
      • Duty Cycle
      • Capacitance
      • Capacitance

  • Functions

      • TRUE RMS
      • True RMS (SK-7660)
      • PEAK HOLD
      • Peak Hold (SK-7660)
      • MAX/MIN
      • MAX/MIN (SK-7661)
      • DIFF
      • Difference
      • DISP HOLD
      • Display Hold
      • AUTO ZERO
      • Zero Adjustment (DCA)
      • APO
      • Auto Power Off

  • Features

    • Up to 400A AC/DC.
    • Conductor dia. : Φ27mm max.
    • Automatic zero adjustment in DCA range.
    • Rubber-molded rotary switch and trigger.
    • Test lead fixable on the side.
    • True RMS, Peak hold function (SK-7660).
    • MAX/MIN measurement (SK-7661).

  • Specifications

    • Display (LCD)
    • 4000 count LCD, Maximum reading 4050
    • Sampling Rate
    • 3 times / sec
    • Renge Selection
    • Auto Ranging
    • Conductor Diameter
    • φ27mm Max.
    • Power Supply
    • 1.5V R03 or AAA Batteries (x2)
    • CE Mark
    • CATⅢ 300V, CATⅡ 600V and EMC
    • Dimensions & Weight
    • 170(H) x 58(W) x 27(D)mm, Approx. 160g
